Technical Specifications and Key Features of the John Deere 412R Sprayer

Choose the 412R if you need a self-propelled sprayer with a high-clearance, 1200-gallon solution tank and customizable boom options up to 132 feet. This model supports advanced ExactApply™ nozzle control, improving application accuracy while reducing overlap. Its PowerTech 9.0L engine delivers up to 326 hp, allowing reliable performance in varied terrain and large acreage operations.

For operators prioritizing speed and comfort, the 412R offers a maximum transport speed of 35 mph and an air-suspended cab designed for long hours in the field. The CommandDrive™ powertrain automatically adjusts engine speed and wheel torque for optimal fuel use and traction. Four-wheel steering and AutoTrac™ RowSense™ improve navigation between rows, even in late-season crops.

Precision farming compatibility is built-in, including JDLink™ for real-time machine monitoring, and full integration with the John Deere Operations Center. Section Control and Turn Compensation reduce waste and ensure consistent coverage. Factory-installed StarFire™ GPS receiver and optional BoomTrac Pro™ height control further enhance spraying accuracy.

John Deere 412R Sprayer Detailed Specifications Overview

Choose the John Deere 412R sprayer if you need a high-capacity, high-clearance solution with a 1,200-gallon stainless steel tank and 132-inch underframe clearance. This configuration supports efficient coverage in tall crops and minimizes crop contact during late-season applications.

The 412R uses a 9.0L PowerTech engine delivering 326 horsepower, ensuring consistent power under heavy load. The CommandDrive™ transmission manages power distribution automatically and adjusts wheel slip for optimal fuel use and traction across varying field conditions.

Factory-installed ExactApply™ system provides up to 30 section control zones and pulsing nozzle technology at 15Hz, maintaining consistent pressure and droplet size. This reduces overapplication and drift, especially at higher speeds. Nozzles support turn compensation and individual control to boost accuracy in variable-width passes.

Spraying speed ranges from 12 to 20 mph, with cruise control and auto steer via John Deere AutoTrac™ guidance, which reduces operator fatigue and maximizes row alignment. Boom widths are available in 90-, 100-, or 120-foot options, with carbon fiber material reducing boom bounce and maintaining spray height precision.

The integrated JDLink™ connectivity allows real-time machine and agronomic data sharing, compatible with the John Deere Operations Center. This supports remote diagnostics and easier fleet coordination. Maintenance access is tool-free at key points, including fill stations, filters, and service panels.

Use the optional Load Command™ system to cut fill time to about 3 minutes and reduce downtime between loads. Pair this with the integrated air purge system to quickly clean plumbing without exiting the cab.

Engine Power Output and Fuel System Configuration of the John Deere 412R

Choose the 412R if you require consistent performance from a 326 hp-rated engine with a peak output of 355 hp. The John Deere PowerTech™ 9.0L engine delivers torque precisely where needed, maintaining power under load without compromising speed or efficiency.

The high-pressure common rail (HPCR) fuel system ensures precise fuel metering and atomization. This configuration supports optimal combustion, contributing to reduced fuel consumption and lower emissions under field conditions. The electronic fuel injection system adapts dynamically to varying loads, keeping the engine running smoothly during demanding spray operations.

Use Ultra Low Sulfur Diesel (ULSD) with Diesel Exhaust Fluid (DEF) to meet Final Tier 4/Stage V emission regulations. The integrated exhaust gas recirculation (EGR) and selective catalytic reduction (SCR) technologies minimize nitrogen oxide (NOx) output while maintaining full engine performance.

The fuel tank holds approximately 120 gallons (454 liters), providing extended runtime without frequent refueling. DEF capacity sits at 11 gallons (41.6 liters), supporting multi-day application windows in larger fields. Regularly monitor fuel filtration elements through the in-cab diagnostics system to prevent performance degradation during peak operations.

Spraying Capacity Parameters and Boom Control Technologies in the 412R Model

Choose the 412R if you need a sprayer that delivers up to 1,200 gallons of solution capacity combined with advanced boom precision. The stainless-steel tank reduces chemical residue and corrosion risk, supporting clean-out and reuse between applications.

Control flow rates with a solution pump rated at 300 gallons per minute and a boom system that extends up to 132 feet. This coverage reduces overlap on large fields and supports faster job completion without sacrificing accuracy.

• Maximum tank capacity: 1,200 gal (4,542 L)
• Boom width options: 90, 100, 120, or 132 ft
• Spray pressure range: 20–120 psi
• Pump output: 300 GPM centrifugal

Reduce drift and improve droplet targeting with the optional ExactApply™ system, which offers pulse-width modulation at 15 or 30 Hz. This system adjusts nozzle flow individually based on ground speed and rate targets, maintaining consistent droplet size even around turns.

The 412R also supports BoomTrac™ Pro 2, which manages five-sensor height control and auto-tilt. This ensures optimal boom height above the crop canopy, even on uneven terrain, helping reduce crop damage and maintain precise spray coverage.

1. Use ExactApply™ to maintain consistent application rates across varying speeds
2. Engage BoomTrac™ Pro 2 for automatic terrain-responsive boom height adjustment
3. Select wider booms for fewer passes and lower soil compaction

The 412R’s integration of high-capacity spraying and intelligent boom control supports precise application while optimizing field efficiency.

Cab Design Features and Integrated Operator Assistance Systems

Choose the 412R if you need a cab that maximizes operator comfort and precision control. The CommandView™ 4 Plus cab includes an air-suspended seat with lumbar support and active climate control, reducing fatigue during long spraying sessions. Noise levels stay below 74 dB, allowing clear communication and concentration.

Use the G5Plus CommandCenter™ for intuitive access to machine settings, diagnostics, and field guidance. Its 12.8-inch touchscreen delivers fast response times and customizable views. Add the optional 4-post ActiveSeat™ II suspension to further stabilize the ride, especially on uneven terrain.

Rely on AutoTrac™ integrated steering for repeatable pass-to-pass accuracy down to 2.5 cm with RTK corrections. Combine it with Vision and BoomTrac™ Pro 2 systems to maintain boom height and coverage automatically, even on slopes and variable canopy.

Enable JDLink™ connectivity for live machine tracking, remote diagnostics, and performance monitoring. Operators can receive remote software updates and support without interrupting fieldwork. Integrate the optional 360-degree LED lighting package for optimal visibility during early morning or nighttime applications.
