2019 John Deere 3046R Tractor Specifications and Features

The 2019 John Deere 3046R offers impressive power and flexibility for various tasks. With a 46 horsepower engine and compact design, it excels in tight spaces without compromising on performance. The 3046R comes with a 12F/12R PowerReverser transmission, providing smooth gear shifts and responsive control for a wide range of applications.

The hydraulic system is designed for efficiency, with a pump capacity of 13.2 gpm, ensuring quick and reliable attachment operation. Coupled with a 2,000-lb lift capacity, it offers strong performance for handling heavy loads with precision. The 3046R is equipped with a mid PTO, allowing users to easily power compatible implements like mowers and blowers.

For maneuverability, the 3046R features a tight turning radius of just 11.2 feet, making it ideal for navigating around obstacles in narrow spaces. The four-wheel drive system ensures excellent traction, especially in challenging terrain. Whether for landscaping, light construction, or general farm work, the 3046R provides the versatility and reliability needed to get the job done effectively.

2019 John Deere 3046R Specs

The 2019 John Deere 3046R is a compact utility tractor designed for versatility and performance across a variety of tasks. With a powerful engine and reliable features, it is built to handle tough work on the farm, construction site, or your property.

It is equipped with a 3-cylinder, 45.3 horsepower engine, delivering a smooth and efficient powertrain. The engine operates at 2,600 RPM, ensuring solid power output for demanding tasks. It also features a 4WD system for increased traction, enabling it to tackle uneven terrain and challenging conditions.

• Engine: 45.3 HP, 3-cylinder diesel, 2,600 RPM
• Transmission: 12 forward and 12 reverse gears, Hydrostatic
• Lift Capacity: 1,700 lbs (rear lift)
• Fuel Tank Capacity: 12.5 gallons
• Operating Weight: 3,130 lbs
• Dimensions: 110.8 in (length) x 53.5 in (width) x 88.2 in (height)

The tractor’s hydraulic system ensures high lifting capacity, providing ample support for heavy-duty implements. It comes with a rear PTO (Power Take-Off) that delivers sufficient power for attachments like mowers, tillers, and post-hole diggers.

The ergonomic controls, including a digital dash, make operation straightforward. The seat is designed for comfort during long working hours, and the high ground clearance ensures the tractor can easily navigate obstacles.

This model is ideal for small to medium-sized farms, construction jobs, or land maintenance. Its performance, fuel efficiency, and ease of use make it a solid choice for anyone looking for a reliable compact tractor.

Engine Power and Performance Details

The 2019 John Deere 3046R is equipped with a 3-cylinder, 2.4L diesel engine that delivers a maximum power output of 46 horsepower. This engine features a turbocharged design, ensuring optimal fuel efficiency and improved performance, even under heavy load conditions.

With a peak torque of 125 Nm at 1,500 RPM, the 3046R provides excellent low-end power for tough tasks, from heavy lifting to ground engagement. The engine’s power-to-weight ratio is well-balanced, ensuring smooth operation while maintaining strong pulling capacity across a variety of applications.

The high-performance engine is coupled with a 12F/12R transmission, offering seamless shifting and enhanced maneuverability. Whether in tight spaces or working on larger fields, the transmission provides flexibility while maintaining efficient use of engine power.

Thanks to its high fuel efficiency, the 3046R reduces downtime spent on refueling, making it a practical choice for long hours in the field. The combination of responsive engine performance and durable components makes the 3046R a reliable machine for a range of farming and landscaping jobs.

Hydraulic System and Lift Capacity

The hydraulic system of the 2019 John Deere 3046R provides excellent lifting power, designed to handle demanding tasks with ease. The system offers a maximum hydraulic flow rate of 13.2 gpm (50 l/min), ensuring quick and smooth operation. Whether lifting heavy loads or using attachments, the system’s capacity supports various farm and construction duties efficiently.

Lift capacity is a standout feature, with a maximum lift height of 126.5 inches (3.22 meters) and a lift capacity of 1,763 lbs (800 kg) at full height. This combination allows operators to move and position materials with precision. The loader’s reach and power are ideal for handling various types of work, from moving hay bales to lifting large equipment.

The John Deere 3046R’s hydraulic system also supports a high-performing auxiliary hydraulic option, delivering 18.3 gpm (69.3 l/min) at peak flow for attachments. This makes it versatile for a wide range of attachments, ensuring effective operation in both agricultural and construction environments.

Maintenance and Service Intervals

For the 2019 John Deere 3046R, regular maintenance is key to ensuring peak performance and reliability. Follow the recommended intervals to keep your tractor in optimal working condition.

Engine Oil and Filter: Change the engine oil and replace the oil filter every 200 hours of operation or once a year, whichever comes first. Use high-quality oil that meets the specifications outlined in the owner’s manual.

Hydraulic Fluid and Filter: Inspect and replace the hydraulic fluid and filter every 1,000 hours or annually. The hydraulic system is crucial for proper lifting and handling, so regular servicing ensures smooth operation and extends system life.

Air Filter: Replace the air filter every 500 hours. In dusty conditions, it may need more frequent checks and replacements. Clean filters improve engine efficiency and prevent contaminants from entering the engine.

Fuel Filter: Replace the fuel filter every 500 hours or at least once a year. Clean filters ensure the fuel system runs smoothly and prevent clogging, which could impact engine performance.

Battery: Inspect the battery every 100 hours for signs of corrosion or wear. Clean the terminals and check the charge level regularly to avoid power issues.

Tires: Check tire pressure and condition every 100 hours. Proper tire inflation helps maintain stability and prevents uneven wear.

Cooling System: Inspect the radiator, coolant level, and hoses every 200 hours. Flush the cooling system every 2 years to avoid overheating and ensure the engine operates within optimal temperature ranges.

Belts and Hoses: Check the condition of belts and hoses every 200 hours. Replace any that show signs of wear or damage to prevent breakdowns during operations.

Transmission Oil: Check the transmission fluid every 500 hours. Keeping it at the proper level ensures smooth shifting and prevents excessive wear on transmission components.

Grease Points: Lubricate all grease points every 50 hours to prevent excessive wear and ensure moving parts operate smoothly.

By following these service intervals, you can extend the life of your John Deere 3046R and ensure reliable performance for years to come.
